Applications demanding long reach and high breaking power require an XL series boom.
Applications include gyratory crushers in mines and quarries and grizzlies in mines. These series, same as M-series, feature a triangular design.
Boom swing with slew ring enables wider coverage and easier service access as well as constant swing torque.
|Maximum reach, m||13.4|
|Nominal horizontal reach (H), m||10.5|
|Nominal vertical reach (V), m||9.8|
|Base dimensions, m||1.40|
|Recommended hammer types||2577 - 4099|
|Recommended power packs||HU 45 - HU 55|
