XM750HD
XM-series is specially designed for mining markets. Proven design combined to over dimensioning makes this a convenient and safe choice. XMbooms also feature a multi-fit pedestal, that makes replacing existing, worn-out boom systems more convenient. In addition the number of different parts is cut to minimum by e.g. fitting same cylinders for all boom functions.
| Weight, kg | 9100 |
| Maximum reach, m | 10.4 |
| Nominal horizontal reach (H), m | 7.9 |
| Nominal vertical reach (V), m | 6.8 |
| Swing, ° | 170 |
| Base dimensions, m | 1.52 x 1.22 |
| Recommended hammer types | 2155 - 3288 |
| Recommended power packs | HU 37 - HU 55 |
